| Features |
|---|
| – Heater screwed in with a hook key |
| – Replaceable heating element without the need to empty the fluid from the tank |
| – Modular housing |
| – Durable construction |
| – Easy installation |
| – Surface load capacity of 1.5W/cm² for oil |
| – Surface load capacity of 3.0W/cm² for water and similar fluids |
| Technical specifications | |
|---|---|
| Power | from 350W to 2500W |
| Voltage | 230V, 400V, 3x400V |
| Length | from 300mm to 1000mm |
| Diameter | 35mm |
| Housing material, threaded heads | stainless steel |
| Thread connection | G2″ |
| Connection protection | plastic cover (angled) |
| Temperature control | 0-40°C, 0-120°C, 2-77°C, 30-75°C*, 30-85°C* (*400V) |
| Protection rating | IP54 |
| Cold zone | min. 50mm |
| Operating conditions | Horizontal |
* Other parameters available on request
| Applications |
|---|
| – Heating of water |
| – Heating of oil |
| – Heating of technological baths |
Thread G2″
How to order?
When placing an order, please specify:
