| Features |
|---|
| Heater mounted with screws to the flange |
| Replaceable heating cartridge – no need to drain the tank |
| Modular housing |
| Durable construction |
| Easy installation |
| Surface load of 1.5 W/cm² for oil |
| Surface load of 3.0 W/cm² for water and similar media |
| Technical Specifications | |
|---|---|
| Power output | from 1000 W to 8100 W |
| Voltage | 230V, 400V, 3x400V |
| Length | from 500 mm to 2000 mm |
| Diameter | 51mm |
| Sheath material, threaded head | stainless steel |
| Flange diameter | DN50/80/100/150 PN16 |
| Threaded connection | M5 |
| Connection protection | angled metal cover |
| Protection rating | IP54 |
| Cold zone | min. 50mm |
| Operating conditions | Horizontal |
* Other parameters available on request
| Applications |
|---|
| Water heating |
| Oil heating |
| Heating of process baths |
How to order?
When placing an order, please specify:
